• LPCB certified to EN54-3, 17 & 23 and Kiwa Telefication & DBI certified to EN54-13.
• Also certified to the relevant parts of EN54 with Swedish certification body SBSC.
• Provides ‘W-2.75-9’ rated light distribution. Also rated as a W-4-4 VAD.
• Impressive 103dB(A) sound output @ 1m.
• Onboard short-circuit loop isolator.
• 13.5mA typical alarm current (550µA typical quiescent current) @ 27-40V DC (VAD lit, sounder on max).
• Group addressing facility allows multiple devices to be operated simultaneously.
• 4 selectable volume levels and 32 selectable tones.
• IP33C (Type B) rated.



Technical Specifications

Approvals/certifications	Certified by SBSC to the relevant parts of EN54, Certified to EN54-13 by Kiwa Telefication & DBI, Certified to EN54-3, 23 & 17 by the LPCB.
Protocol/compatibility	Compatible with C-TEC's CAST protocol Addressable Fire Panels.
Application/operation	Designed to be wall mounted. IP33C rated and suitable for use outdoors (note an IP65 rated version is also available).
VAD category & coverage	W-2.75-9 rated light distribution. Also certified as a W-4-4 rated VAD.
Flash rate & colour	0.5Hz / White.
Supply/operating voltage	27 to 40V DC.
Quiescent current	460µA typical.
Nominal SPL (Sound Pressure Level)	103dB(A) when set to tone 1.
Alarm current	13.5mA typical @ 27-40V (VAD lit, Sounder on max).
Indicators	Polling (red LED).
Product dimensions (mm)	114mm diameter x 131mm deep.
IP Rating	IP33C (Type B).
Weight	315g.
Operating conditions/temperature	-10ºC to +55ºC. Max. 95% RH (Non-condensing).
