Fyreye MkII Addressable Input/Output Module with S/C Isolator (loop powered)
The ZASC-MI is supplied in a modern enclosure (2 gang box size) with well protected electronic circuit board to minimize any damages during installation. It is supplied with a back box suitable for surface mount indoor installation. Designed and manufactured to meetĀ the requirement of EN54-18 2005 and EN54-17 2005.
The ZASC-MI can be used to supply a monitored 24Vdc to operate external relays and as a conventional sounder circuit to run bells or beacon flashers where the current consumption prohibits the use of addressable loop powered devices. The unit also includes inputĀ connections to monitor the external power supply status and report the findings to the addressable control panel.
Features
Ā This is not a loop powered device and an adequate 24Vdc input (with battery backup) is needed.
Ā Hand addressed using the 8 way dip switch OR
Ā Softly addressed using our handheld MKII Programmer (part no. 48-004)
Ā Equipped with short circuit line isolator
